Présentation du produit

LeClapet anti-retour à battant en fonte is a reliable, automatic non-return valve designed to prevent reverse flow in water, eaux usées, et systèmes de tuyauterie industrielle. Featuring a robust cast iron or ductile iron body with a hinged disc that swings freely on a pin, this valve opens with forward flow and closes automatically when flow stops or reverses — protecting pumps, compresseurs, and other equipment from damaging backflow. Available with EPDM soft seal (0°C to +80°C) for bubble-tight shut-off or metal-to-metal seal (-10°C to +350°C) for high-temperature applications. The flanged ends conform to BS EN 1092-2:1997 normes, ensuring compatibility with international piping systems. With sizes from 2″ to 24″ (DN50 to DN600) and pressure ratings PN10/PN16, this valve is suitable for a wide range of applications including drinking water, approvisionnement en eau & drainage, traitement des eaux usées, irrigation, CVC, protection incendie, and chemical & energy industries. The fusion-bonded epoxy coating provides superior corrosion protection for long service life. With OEM/ODM customization support, it is the trusted choice for engineers and plant operators worldwide.

Cast iron swing check valve

Spécifications techniques

Cast iron swing check valve

Principales fonctionnalités

1. Swing Check Design – Low Pressure Drop
2. Dual Seal Options – Soft Seal & Metal Seal
3. Robust Ductile Iron Disc – Durable & Corrosion Resistant
4. Fusion-Bonded Epoxy Coating – Superior Corrosion Protection
5. BS EN 12334 Compliant – International Standard
6. Wide Temperature Range – -10°C to +350°C

Working Principle

The swing check valve operates through a simple yet reliable mechanism:

• 1. Forward Flow (Valve Open): When upstream pressure exceeds downstream pressure, the disc swings open on its hinge pin, allowing flow to pass through with minimal resistance.
• 2. Reverse Flow or Stop (Valve Closed): When flow stops or reverses, gravity and backflow pressure cause the disc to swing back onto the seat, creating a tight seal.
• 3. Horizontal Installation: Swing check valves must be installed horizontally (or in slightly sloping lines) to allow gravity to assist in closing the disc.

Cast iron swing check valve

Applications

1. Approvisionnement en eau & Distribution
2. Wastewater Treatment
3. Systèmes de protection incendie
4. Lignes de processus industriels

Emballage et expédition

L'emballage dépend du type de produit et de la quantité. Options include wooden crates or carton boxes with proper protection for flange faces. L'expédition peut être organisée par voie maritime, chemin de fer, air, ou selon la demande du client.

Profil de l'entreprise

Luoyang Datang Energy Tech Co., Ltée est un fournisseur professionnel de vannes industrielles, dedicated to providing reliable flow control solutions for water treatment, CVC, protection incendie, et systèmes de tuyauterie industrielle dans le monde entier. All products are manufactured to international standards with ISO 9001 attestations. Avec plus 10 années d'expérience, une installation moderne de 80,000 m², et 200+ employés professionnels, nous servons les clients dans 10+ pays avec des produits de qualité, prix compétitif, et livraison fiable.

Cast iron swing check valve

Conditions de paiement

T/T, L/C à vue, Western union, Paypal, Apple Payer, Google Payer, Carte de crédit, etc..

FAQ | Frequently Asked Questions

T1: Can a swing check valve be installed vertically?

UN: Non. Swing check valves must be installed horizontally (or in slightly inclined piping) because gravity is required for the disc to return to the seat when flow stops. Vertical installation prevents the disc from closing completely, resulting in backflow.

T2: What is the difference between soft-seated and metal-seated valves?

UN: Soft-seated (EPDM) valves provide zero-leakage (étanche aux bulles) shut-off and operate within a temperature range of 0°C to +80°C; ils conviennent à l'eau, eaux usées, et produits chimiques doux. Metal-seated (metal-to-metal) valves operate between -10°C and +350°C and are suitable for steam, high-temperature fluids, and abrasive media, though they have a slightly higher leakage rate (Classe IV).

T3: What is the maximum working pressure for this valve?

UN: The standard configuration supports a maximum working pressure of PN10/PN16. Higher pressure ratings are available upon request; please contact our sales team for more information.

T4: What is the difference between a swing check valve and a lift check valve?

UN: Swing check valves use a disc that swings on a hinge; they offer low pressure drop (approx. 0.5 psi), must be installed horizontally, and are suitable for large-bore and low-pressure-drop applications. Lift check valves use a disc that lifts vertically; they offer superior sealing but have a higher pressure drop and can be installed either vertically or horizontally.
