PARAMETRI PROIZVODA

Raspon temperature	-196°C to +600°C
Standard dizajna	ASME B16.11, ISO, IZ, BS, ON, GB, GOST
Oblik	Equal (All Ports Same Size)
Površinska obrada	Pickling, Annealing, Polishing, Sand Blasting, Shot Blasting
Process	Investment Casting / Forging / Precision Machining
Head Type	Kvadrat / Hexagonal / Krug
Primjena	Ulje & Plin, Kemijska obrada, Proizvodnja električne energije, Marine, Izgradnja
Certifikacija	CE (PED 2014/68/EU)

ZATRAŽITE PONUDU

Opis

ZATRAŽITE PONUDU

Opis

Pregled proizvoda

TheJednaki T-kratnik s navojem od nehrđajućeg čelika is a high-performance pipe fitting designed for reliable branch connections in demanding industrial piping systems. Manufactured from premium stainless steel (SS304/SS316/SS304L/SS316L) with precision investment casting and machining, this equal tee provides exceptional corrosion resistance, izdržljivost, and long service life in harsh environments. The female threaded ends conform to NPT (ASME B1.20.1), BSPT (ISO 7-1), or BSPP (ISO 228-1) standardima, enabling secure, leak-proof connections without welding. Available in sizes from 1/8″ to 4″ (DN6 to DN100) with pressure ratings from Class 150 do 2500 and temperature ranges from -196°C to +600°C, this fitting is suitable for a wide range of applications including oil & plin, chemical processing, proizvodnja električne energije, morski, and construction industries. With CE certification and OEM/ODM customization support, this equal tee ensures safe, reliable branching of fluid flow in critical high-pressure and high-temperature systems.

Jednaki T-kratnik s navojem od nehrđajućeg čelika

Tehničke specifikacije

Parametar	Specifikacija
Naziv proizvoda	Jednaki T-kratnik s navojem od nehrđajućeg čelika
Material Grades	SS304, SS304L, SS316, SS316L, SS321, 1.4401, 1.4403, Duplex F51, F53
Material Standard	ASTM A182, AISI, IZ, U, ON, GB
Tip	Equal Tee
Raspon veličina	1/8″ – 4″ (DN6 – DN100)
Connecting Size	1/8″ x 1/8″, 1/4″ x 1/4″, 1/2″ x 1/2″, 3/4″ x 3/4″, 1″ x 1″, 2″ x 2″, 3″ x 3″, 4″ x 4″
Vrsta veze	S navojem (Female NPT / BSPT / BSPP)
Thread Standards	NPT: ASME B1.20.1 / BSPT: ISO 7-1 / BSPP: ISO 228-1
Nazivni tlak	Klasa 150 – Class 2500 (PN10 – PN420)

Jednaki T-kratnik s navojem od nehrđajućeg čelika

Ključne značajke

Premium Stainless Steel Construction – Corrosion & Heat Resistant
Equal Tee Design – Unrestricted Flow Distribution
Threaded Connection – No Welding Required
Wide Pressure & Temperature Range – Class 150 do 2500
Usklađenost s višestrukim međunarodnim standardima
Premium Surface Finish – Enhanced Corrosion Protection
CE Certified – International Compliance
OEM / Podrška za prilagodbu ODM-a

Prijave

Ulje & Plinovodi
Kemijski & Petrokemijska obrada
Proizvodnja električne energije
Marine & Offshore
Cryogenic & LNG Services

Jednaki T-kratnik s navojem od nehrđajućeg čelika

Pakiranje i otprema

Pakiranje ovisi o vrsti i količini proizvoda. Options include carton boxes, drveni sanduci, or pallets with proper protection for threaded ends. Dostava se može organizirati morem, željeznička pruga, zrak, ili prema zahtjevu kupca.

Profil tvrtke

Luoyang Datang Energy Tech Co., doo. is a professional industrial pipe fitting and valve supplier, dedicated to providing reliable piping solutions for oil & plin, kemijski, proizvodnja električne energije, morski, i industrijskih cjevovodnih sustava diljem svijeta. All products are manufactured to international standards with CE and ISO 9001 potvrde. S preko 10 godine iskustva, moderan objekt od 80,000 m², i 200+ stručnih djelatnika, služimo klijentima u 10+ zemlje s kvalitetnim proizvodima, konkurentne cijene, i pouzdanu isporuku.

Uvjeti plaćanja

T/T, L/C po viđenju, Western Union, PayPal, Apple Pay, Google Pay, Kreditna kartica, itd.

Jednaki T-kratnik s navojem od nehrđajućeg čelika

FAQ

P1: What is the difference between NPT and BSPT threads?

A: Both NPT (National Pipe Taper) and BSPT (British Standard Pipe Taper) are tapered threads that achieve a seal through thread deformation; they require the use of thread sealant or PTFE tape. They differ in thread angle (NPT: 60°, BSPT: 55°) and pitch, and are not interchangeable. Please select the correct thread standard based on your piping system.

Q2: What is the difference between an equal tee and a reducing tee?

A: An equal tee has ports of the same diameter and is used to create a branch connection of the same size as the main pipeline. A reducing tee has a branch port of a different diameter and is used to connect pipes of different sizes. The choice depends on your pipe sizes and flow distribution requirements.

Q3: What is the difference between SS304 and SS316 stainless steel?

A: SS316 sadrži molibden, offering superior resistance to pitting and crevice corrosion in chloride environments compared to SS304. SS316 is suitable for seawater, chemical processing, and marine applications. SS304 is suitable for general corrosive applications and is more cost-effective.

Q4: Can this tee be used for high-pressure applications?

A: Da. This tee is available in pressure ratings from Class 150 do 2500, making it suitable for demanding applications such as high-pressure oil and gas pipelines, chemical processing, and power generation. Please select the appropriate rating based on the system’s design pressure.

P5: Why is surface treatment important?

A: Surface treatment (pickling, polishing, sandblasting, itd.) removes surface impurities and oxide layers, enhances corrosion resistance, and provides a smooth surface that is easy to clean. Proper surface treatment is crucial for sanitary applications and corrosive environments.
