Introduction of Standard PPR Tube Plumbing PN12.5/PN16/PN20/PN25 Green Plastic PPR Water Pipe

PPR pipe (full name Polypropylene Random Copolymer Pipe, is a high-performance plastic pipe made of high-quality random copolymer polypropylene raw materials. Due to its high temperature resistance, pressure resistance, environmental protection and non-toxicity, it is widely used in building hot and cold water systems, HVAC engineering, drinking water transportation and industrial fluid transmission, and is an ideal substitute for traditional metal pipes.

Characteristics and Features of Standard PPR Tube Plumbing PN12.5/PN16/PN20/PN25 Green Plastic PPR Water Pipe

High temperature and high pressure resistance

Long-term working temperature can reach 70°C, short-term high temperature resistance to 95°C, excellent pressure bearing performance (common pressure level PN20, PN25).

Environmental protection and health

The raw materials are pure and non-toxic, meet drinking water standards (such as FDA, EN ISO and other certifications), do not breed bacteria, and ensure the safety of water quality.

Corrosion and anti-scaling

Acid and alkali resistance, strong chemical corrosion resistance, smooth inner wall, not easy to scale, long-term use of stable flow.

Hot melt connection, strong sealing

Adopting hot melt socket technology, there is no risk of leakage at the connection, and the integrated structure improves system reliability.

Lightweight and easy to construct

The weight is only 1/8 of that of metal pipes, which is convenient for transportation and installation, reducing labor costs.

Long life and low maintenance

The designed service life is more than 50 years, maintenance-free, and the overall cost is low.

Energy-saving and heat preservation

The thermal conductivity is low (only 1/200 of metal pipes), which reduces heat loss and is suitable for hot water systems.

(Standard PPR Tube Plumbing PN12.5/PN16/PN20/PN25 Green Plastic PPR Water Pipe)

Specifications of Standard PPR Tube Plumbing PN12.5/PN16/PN20/PN25 Green Plastic PPR Water Pipe

Standard PPR tube plumbing pipelines use reputable remedies for water systems. They are available in environment-friendly color. Several stress rankings exist: PN12.5, PN16, PN20, PN25. These numbers indicate the pipeline’s optimum functioning stress ability at 20 ° C. PN12.5 handles 12.5 bar. PN16 manages 16 bar. PN20 takes care of 20 bar. PN25 handles 25 bar. Pick the ranking matching your system pressure demands.

These pipelines are readily available alike diameters. Sizes consist of 20mm, 25mm, 32mm, 40mm, 50mm, 63mm, 75mm, 90mm, 110mm, 160mm. Wall density differs accordingly. Thicker wall surfaces sustain greater pressure ratings. The product is polypropylene arbitrary copolymer. This plastic is solid and sturdy.

PPR pipelines work well with cold and hot water. Their operating temperature level variety is large. They securely deal with water from 0 ° C as much as 70 ° C constantly. Temporary peaks can get to 95 ° C. The product resists scaling and corrosion. It will not corrosion like steel pipes. Chemicals in the water won’t easily harm it.

Security is necessary. These environment-friendly PPR pipelines make use of food-grade material. They fulfill requirements for drinkable water. The plastic includes no hefty steels. Water remains clean and preferences great. Setup is uncomplicated using thermal combination. Warm melts the pipeline and fitting ends. They fuse together developing a permanent, watertight joint. No glues or solvents are needed. This technique is dependable.

PPR pipes are lightweight. They are less complicated to transfer and handle than metal pipes. Their smooth internal surface minimizes water flow resistance. This assists maintain excellent stress. Power loss is decreased. Sound from flowing water is also reduced.

These pipes match several applications. Utilize them for home chilly water lines. Utilize them for home warm water lines. They work for main heating unit. They work for pressed air lines. They work for industrial liquid transportation. The green shade assists recognize them quickly on website.

(Standard PPR Tube Plumbing PN12.5/PN16/PN20/PN25 Green Plastic PPR Water Pipe)

Applications of Standard PPR Tube Plumbing PN12.5/PN16/PN20/PN25 Green Plastic PPR Water Pipe

These environment-friendly PPR pipes take care of water supply well. They can be found in various pressure qualities. PN12.5 fits lower stress jobs. PN16 benefits lots of typical home uses. PN20 fits greater stress needs. PN25 deals with the hardest stress demands. The eco-friendly color frequently signifies hot water lines. These pipelines are difficult against warm and chemicals. They last a very long time without rusting or scaling up inside. This maintains water clean and flowing right.

Building contractors use them commonly in residences and homes. They link taps, showers, and commodes. They work well for the pipelines inside walls and under floorings. Hot water systems depend on them, particularly the higher PN qualities like PN20 and PN25. They lug water securely to radiators and warmed floors. Central heating boilers need reputable pipelines like these.

Factories and labs require solid pipes as well. These PPR tubes move water for makers and cleaning. They manage compressed air lines securely. Farms use them for irrigation systems and animal drinking water arrangements. Their smooth withins prevent obstructions and aid water scoot. They resist damage from typical plant foods and cleaning things.

Plumbing technicians like working with PPR pipes. They reduced quickly and join rapidly with heat fusion. This makes solid, leak-proof links whenever. The product stays adaptable in cold weather. It doesn’t get weak and crack. Setup is simple. Maintenance demands are extremely low. You get a dependable system for several years.

Packing and Shipment

Depends on the products and qty,we could make the packing of coiling,rolls,bundle packing,crates or boxes,etc.

Shipment:By sea,railway,by air or as customer’s request.

Company Profile

Luoyang Datang Energy Tech Co., Ltd. is a leading Chinese manufacturer specializing in high-quality plastic pipes and fittings. Equipped with state-of-the-art automated production lines and supported by a team of 200 professionals, we offer an extensive product line comprising over 150 types of plastic pipes and fittings designed for water supply and drainage systems, gas transmission, and floor heating systems. Our main products include PVC Pipes and Fittings, PE (HDPE) Pipes and Fittings, PPR Pipes and Fittings, and PEX Floor Heating Pipes.

Should you have any inquiries regarding HDPE Pipe Fitting, please do not hesitate to contact us!

Tel.:0086-183 3790 0677

Wechat: 0086-183 3790 0677

Whatsapp: 0086-183 3790 0677

Email: sales@pipesandfittings.net

Payment Terms

T/T,L/C at sight,Western Union & Paypal,etc.

5 FAQs of Standard PPR Tube Plumbing PN12.5/PN16/PN20/PN25 Green Plastic PPR Water Pipe

PPR Tube Plumbing FAQs: PN12.5 to PN25 Green Pipes

What is PPR pipe?
PPR pipe is green plastic plumbing pipe. It stands for Polypropylene Random Copolymer. This material is durable. It resists heat well. It handles water pressure effectively. PPR pipes are common for hot and cold water systems. They work in homes and buildings.

What do PN12.5, PN16, PN20, PN25 mean?
These numbers show the pipe’s pressure rating. PN means Nominal Pressure. It tells you the maximum water pressure the pipe can handle continuously at 20°C. PN12.5 handles lower pressure. PN16 handles more. PN20 is common for household systems. PN25 handles the highest pressure. Choose the PN rating based on your system’s pressure needs.

How hot can the water be?
PPR pipes handle hot water well. They work continuously with water up to 70°C. They can handle short bursts of hotter water, up to 95°C. This makes them safe for standard hot water systems. Avoid exceeding these temperatures long-term.

How do you install PPR pipes?
Install PPR pipes using heat fusion. Cut the pipe ends clean and square. Heat the pipe end and the fitting socket with a special tool. Push the heated pipe into the fitting. Hold it steady. The melted plastic cools. It forms a permanent, leak-proof joint. No glue is needed. Threaded connections are also possible with specific fittings.

Is PPR pipe safe for drinking water?
Yes, PPR pipe is safe for drinking water. High-quality PPR material meets food-grade standards. It doesn’t add bad tastes or smells to the water. It resists corrosion and scaling. It keeps water clean. Always use pipes certified for potable water use.

(Standard PPR Tube Plumbing PN12.5/PN16/PN20/PN25 Green Plastic PPR Water Pipe)
